MCB IEC60898 1P 2P 3P 4P 63 Amp Types for L7 circuit breakers home mcb 2amp

Short Description:

Applications

The series S7A high break capacity of mini circuit breaker features attractive and compactappearance, reasonable structure, excellent performance and high breaking capacity. It adopts the standard rail for installation, convenient and swift. It main acts for overload and short-circuit moreover, as low frequency of open, close and switch at the line.

This product conforms to the requirement or GB 10963 & IEC60898 standards.

Send email to us Download as PDF

Product Detail

Product Tags

Basic Specification and Main Parameters
Rated voltage	50/60Hz,240/415V
Rated current	1,3,5,6,10,15,16,20,25,32,40,50,60,63A
Making and breaking capacity	6000A Icn 10KA Ics 7.5kA
The type of the instant trippingunit and tripping curent	B type 3ln~5ln C type 5ln~10ln
The type of the instant trippingunit and tripping curent	D type 10ln~50ln
Mechanical lifes(times)	10000
Electricalifes(times)	4000
