QL Plug-in Circuit Breakers
Specification
| Product Number | Ampere rating |
Rated VoltagelVac) |
#of poles |
| HQL115 | 15 | 120/240 | 1 |
| HQL120 | 20 | 120/240 | 1 |
| HQL130 | 30 | 120/240 | 1 |
| HQL140 | 40 | 120/240 | 1 |
| HQL150 | 50 | 120/240 | 1 |
| HQL160 | 60 | 120/240 | 1 |
| HQL175 | 75 | 120/240 | 1 |
| HQL1100 | 100 | 120/240 | 1 |
| HQL215 | 15 | 120/240 | 2 |
| HQL220 | 20 | 120/240 | 2 |
| HQL230 | 30 | 120/240 | 2 |
| HQL240 | 40 | 120/240 | 2 |
| HQL250 | 50 | 120/240 | 2 |
| HQL260 | 60 | 120/240 | 2 |
| HQL275 | 75 | 120/240 | 2 |
| HQL2100 | 100 | 120/240 | 2 |
| HQL315 | 15 | 240 | 3 |
| HQL320 | 20 | 240 | 3 |
| HQL330 | 30 | 240 | 3 |
| HQL340 | 40 | 240 | 3 |
| HQL350 | 50 | 240 | 3 |
| HQL360 | 60 | 240 | 3 |
| HQL375 | 75 | 240 | 3 |
| HQL3100 | 100 | 240 | 3 |
