Shell material: ABS or PC material. Characteristics: Excellent impact resistance, heat resistance, low-temperature resistance, chemical resistance, and electrical performance, with good surface gloss. Certifications: CE, ROHS. Protection grade: IP65. Applications:
It is applicable to indoor and outdoor electrical, communication, fire-fighting equipment, copper and iron smelting, petrochemicals, electronics, power, railways, construction sites, mining sites, airports, hotels, ships, large factories, coastal factories, unloading wharf equipment, sewage and wastewater treatment facilities, environmental pollution control facilities, etc.
Installation method :1. Internal installation
The box has a protruding platform for installing circuit boards or DIN track components inside, as well as built-in copper connection nuts (each waterproof box is equipped with at least two or more conventional M4 copper nuts inside). 2. External installation: It can be directly fixed to the wall through the installation holes at the bottom of the box (it can also be directly fixed to the wall or board with screws or nails through the four corners of the box.
Inlet and outlet holes: The waterproof box can be freely drilled with holes on it according to the customer’s usage requirements. (The position and size of the holes can be processed according to the customer’s specified requirements.)
After the hole is drilled, a matching waterproof clamping joint can be installed to achieve the best waterproof effect.
