TM series fully automatic ac voltage regulatoris on the basis of SVC series product to newly design producs, with good functionssuch as time delay, over voltage, undervoltage etc,the use ofrelay switch output transformertap, quick response, low energyconsumption, can be widely used where need stable voltage like household ,hospital, office , industrial automation and so on

Input voltage range：80V-270V/160V-250V/ 120V-250V/100V-250V AC
Input frequency：50-60Hz
Output voltage：220VAC
Outputprecision：±8%
Efficiency：95%
Phase：Single phase
Meter display status：Input voltage/Output voltage
Working：GREEN,Indicating power ON/OFF
Delaying：YELLOW,Indicating DELAY ON/OFF
Over-v：RED,Indicating if the machine is working regularly
Operating temperature：0-40℃
Storage temperature：-15℃-45℃
Operating relative humidity：10% RH-102%RH; Non-condensing
